AWS90 BS.SI

Size	Vent Width : Parallel / 550-1,200mm , PJ / 450-2,200mm Vent Height : Parallel / 700-2,000mm , PJ / 450-2,000mm Vent Maximum Weight : Parallel / 100kg ,PJ / 160kg Glass Thickness :28-52mm * 최대 사이즈는 가로 x 높이 비율 및 유리 무게에 따라 변동 됩니다 *	Min. Face with	외부 : 커튼월 제외 유리면 (벤트 안보임) / 내부 : 커튼월 제외 벤트 폭 58mm
		Min. -max. system Basic depth	186-311mm / 커튼월 베이스 윈도우
		Max.glass/panel thickness	52 mm
		Max. Weight	100 / 160kg
		Surface finishes	Powder, Anodised, Paint
Thermal	28T ( 6LE + 16AR + 6CL ) : 1.3W/m2k / 기밀성능 0.00m3 / hm2	Air permeability	Class 4
Sound Insulation	47db	Max. Sound reduction Index Rwp	43db
Opening Type	Outward Type: Project Top Hung Parallel-Opening	Watertightness	E 1200
Opening Type	Outward Type: Project Top Hung Parallel-Opening	Impact resistance	Class 4
Uf value of frame	1.7 W/(m2 . K)	Burglar resistance	Up to RC3


Natural Oak	Ivory Oak	Frozen Walnut	Desert Oak	Sahara Oak	Pure Walnut	Burley Oak	Raven Oak


Standard
